| 外壳材质 | Housing Material | 工程塑料 |
| 输出轴承形式 | Bearing at output | 滚珠轴承 |
| 径向负载 | Radial load (10mm from flange) | ≤450(N) |
| 轴向负载 | Shaft axial load | ≤200(N) |
| 静态主轴最大承受压入力 | Shaft press fit force max Static | ≤500(N) |
| 径向间隙 | Radial play of shaft | ≤0.03(mm) |
| 轴向间隙 | Thrust play of shaft | ≤0.1(mm) |
| 背隙（无负载时） | Backlash at no-load | ≤1.5° |
*负载与转速有关，具体数据需参考实际情况。
*Load relates to speed, actual value depends on different situation.
| 减速比 | 额定允许负载（Nm） | 瞬间允许负载（Nm） | 效率（%） | 长度（mm） | 重量（g） | 减速比级数 |
|---|---|---|---|---|---|---|
| 1/4 | 0.3 | 1.0 | 81% | 24.8 | 145 | 1 |
| 1/5 | 0.3 | 1.0 | 81% | 24.8 | 145 | 1 |
| 1/16 | 1.2 | 3.5 | 72% | 32.4 | 173 | 2 |
| 1/20 | 1.2 | 3.5 | 72% | 32.4 | 173 | 2 |
| 1/25 | 1.2 | 3.5 | 72% | 32.4 | 173 | 2 |
| 1/53 | 2.5 | 7.5 | 65% | 41.9 | 213 | 3 |
| 1/62 | 2.5 | 7.5 | 65% | 41.9 | 213 | 3 |
| 1/76 | 2.5 | 7.5 | 65% | 41.9 | 213 | 3 |
| 1/94 | 2.5 | 7.5 | 65% | 41.9 | 213 | 3 |
| 1/117 | 2.5 | 7.5 | 65% | 41.9 | 213 | 3 |
